HLX150 150CC Motor Taxi Street Motorcycle Rear Double Shock Absorber
Details:
| MAIN SPECIFICATION |
| ENGINE |
| Engine Type: | Single-cylinder,air-cooled, 4-stroke |
| Displacement (ml): | 149.6ml |
| Bore X Stroke (mm): | 62×49.5 |
| Compression Ratio: | 9.2:1 |
| Max. Power (kw/r/min) | 8.2/8000 |
| Max. Torque (N.m/r/min): | 10.5/6000 |
| Max. Speed (Km/h): | ≥90 |
| Lubrication: | Pressure ,splash |
| Clutch Type: | Multiplate wet clutch |
| Ignition: | CDI |
| Starting System: | Electric/Kick start |
| Transmission System: | Chain drive |
| CHASSIS |
| Front shock absorber: | hydraulic pressure and spring |
| Rear shock absorber: | hydraulic pressure and spring |
| Chassis structure: | Steel tube and steel plate,rhombic structure |
| Rear fork: | steel |
| Front Brake: | Disc/Drum Brake |
| Rear Brake: | Drum Brake |
| Front Tire: | 2.5-18 |
| Rear Tire: | 3.00-17 |
| Muffler: | steel |
| Steering Head Angle: | 39/41 |
| Wheel rim | Alloy/Spoke |
| Battery: | 12V7Ah |
| DIMENSIONS |
| L X W X H (mm): | 1920*770*1080 |
| Seat Height (mm): | 845mm |
| Wheelbase (mm): | 1290mm |
| Min. Ground Clearance (mm): | 160mm |
| Max. Permissionable Weight (kg): | 150 |
| Rider Capacity: | 2 Persons |
| Dry. Weigth (kg): | 85 |
| Fuel Tank Capacity (L): | 15L |
| Packing Size (mm): | 1480×380×860 |
| Packing Weight (kg): | 105 |
Product description:
1. Motor taxi type is highly welcomed by Africa customers.
2. The simple and optimized design makes the fuel consumption of the engine less than 2.3 L/100KM.
3. The lengthened thickened seat cushion and double strenghten rear shock absorber could take 2-3 passengers.
4. Wider tyres make good trafficability and safty.
5. Full chain cover design avoids the sand dust enter into the engine caused the engine damage.
6. 1 year or 6000 Km quality guarantee demonstrates our confidence in our products and our commitment to our customers.
7. 105 units SKD packing and 210 sets CKD packing help customers save transportation costs and avoid damage during the transportation.
Options:
MP3, USB, Remote Controller, Alarm
Customed Color And Sticker Design Is Accepted
Engine: 125CC/150CC/200CC
Footrest: Rear long footrest / Small rear footrest
Front fender: Steel fender/ plastic fender
Headlight: Round light/Square light
Odometer: Round meter/Square meter
